OLED & LCD Programmable Switches
The IS Series programmable LCD switch offers an exciting product breakthrough in pushbutton switches. This software controlled SMARTSWITCHTM can be programmed to display an infinite variety of text, characters and still or moving images. The NKK SMARTSWITCHTM can be used solo, in conjunction with other electromechanical switches or grouped for more complex switching operations.
BROCHURE DOWNLOAD
SmartSwitch OLED & LCD Programmable Switches & Displays
Frameless OLED Pushbutton – ISF15ACP4
- Part Number: ISF15ACP4 -- High definition, contrast and resolution of 96RGB x 64 pixel in a compact screen and minimal frame.
- Range of 65K colors in 16-bit mode. Operating life of 50,000 hours minimum.
OLED Pushbutton – ISC15ANP4
- Part Number: ISC15ANP4 -- Organic LED technology with 30,000 hours life and 30% less power consumption.
- Range of 65,536 colors in 16-bit mode, 256 colors in 8-bit mode. Full viewing angle of 180 degrees.
OLED Display – ISC01P
-
Download Specifications (PDF)
- Product Data
- Part Number: ISC01P -- Organic LED technology. High resolution of 53RGB x 36 pixels.
- Viewing area: 12.9mm x 9.9mm (horizontal x vertical).
OLED SmartSwitch Rocker – IS18WWC1W
- Part Number: IS18WWC1W -- White monochrome OLED featuring sharp contrast and high resolution with 96 x 64 pixels.
- Wide viewing angle of 180 degrees and large .92" display with exceptional contrast. Organic LED technology in display rocker.
Single Switch Solution – IS-S0108
- Part Number: IS-S0108 -- The Single Switch Solution is the smallest panel-mount indicator and controller on the market.
- It incorporates the award-winning SmartSwitch with a microprocessor and I/O for real-world control functions.
Wide View 36 x 24 Display – IS01BBFEF
- Part Number: IS01BBFEF Programmable to display graphics, alphanumeric characters and animated sequences.
- Integrated liquid crystal display provides a wide viewing angle with high contrast and clarity.
Wide View 36 x 24 Display – IS01BBFRGB
- Part Number: IS01BBFRGB -- Standard with Enhanced Illumination.
- Programmable to display graphics, alphanumeric characters and animated sequences. RGB LED provides numerous color variation
Wide View 64 x 32 Display – IS01EBFRGB
- Part Number: IS01EBFRGB -- Programmable display graphics for alphanumeric characters and animated sequences.
- 64 colors of backlighting can be controlled dynamically. Display with LCD, RGB LED backlighting.
Wide View Compact LCD 36 x 24 Pushbutton – IS15BSAFP4CF
- Part Number: IS15BSAFP4CF Programmable LCD, Vibrant Illumination.
- Perfect for rack mount router and other applications with space limitations.
Wide View Compact LCD 36 x 24 Pushbutton – IS15BSBFP4RGB
- Part Number: IS15BSBFP4RGB -- Compact Size. Perfect for rack mount router and other applications with space limitations.
- Compact body size: 19.0mm (.748") x 18.0mm (.709") compared to Standard body size: 23.13mm (.911") x 20.59mm (.811"). Vibrant Illumination.
Wide View Compact LCD 64 x 32 Pushbutton – IS15ESBFP4RGB
- Part Number: IS15ESBFP4RGB -- Compact Size Combined with High Resolution of 64 x 32 pixels.
- 64 colors of backlighting can be controlled dynamically.
Wide View LCD 36 x 24 Bicolor Pushbutton – IS15BAFP4CF
- Part Number: IS15BAFP4CF -- Standard with Enhanced LED Illumination.
- Broad and even light distribution. Consistent backlighting. Low energy consumption. Programmable LCD with a variety of LED backlighting colors. Rubber dome.
Wide View LCD 36 x 24 RGB Pushbutton – IS15BBFP4RGB
- Part Number: IS15BBFP4RGB -- Standard with Enhanced LED Illumination. Broad and even light diffusion.
- Consistent backlighting with low energy consumption. Programmable LCD with a variety of LED backlighting colors.
Wide View/Long Travel LCD 64 x 32 Pushbutton – IS15EBFP4RGB
- Part Number: IS15EBFP4RGB -- Travel distance of 4.5mm (same as KP01 Series).
- Programmable display graphics for alphanumeric characters and animated sequences.
Wide View/Short Travel LCD 64 x 32 Pushbutton – IS15EBFP4RGB-09YN
- Part Number: IS15EBFP4RGB-09YN -- Short travel distance of 1.8mm..
- Programmable display graphics for alphanumeric characters and animated sequences. 64 colors of backlighting can be controlled dynamically. Pushbutton switch with LCD, RGB LED backlighting.
